Marine Metrology Services

Ship Repair & Shipbuilding Metrology — We’ve got you covered

Marine metrology services from TNT Metrology support ship repair and shipbuilding projects worldwide. Using 3D scanning, dimensional inspection, and precision alignment, we help shipyards, defence contractors, and service teams reduce rework, accelerate dockings, and deliver class-ready results. From shaft lines and gearboxes to hull blocks and retrofit integrations, our experts provide accurate, traceable outputs for every stage of the marine lifecycle.

What We Do for Ship Repair & Shipbuilding

TNT Metrology delivers dimensional control, precision alignment, and reverse engineering tailored for marine environments—dry-dock, afloat, or in yard. We keep refits and new builds on track worldwide.

Shaft line & gearbox alignment — laser tracker alignment of main engines, gearboxes, bearings, and stern tube to minimise vibration and wear.
Hull & block 3D scanning — capture complex hull forms, blocks, and modules as point clouds/meshes for clash-checks and as-built documentation.
Rudder, skeg & propeller inspection — GD&T to CAD, clear colour maps, and traceable reports for class surveys and FAI.
Reverse engineering & retrofit support — create accurate models of legacy components and interfaces to de-risk upgrades and integrations.

What We Do for Marine & Offshore

Our marine metrology services help shipyards and repair teams bring vessels back to service faster with less rework.
We combine 3D scanning, dimensional inspection, and
precision alignment.

  • Jig/fixture & foundation verification — machinery seats, inserts, and bolt patterns validated to CAD.
  • Large-scale scanning — hulls, tanks, and superstructures captured for fairing analysis and fit-ups.

Typical Use Cases
  • Dry-dock shaft line alignment & bearing set-up
  • Block/module fit-up & clash-check
  • Rudder stock, pintle & stern gear surveys
  • Tank/void space mapping and deformation studies
  • Retrofit integrations (scrubbers, BWTS, sensors)

Class & quality frameworks: ABS, DNV, Lloyd’s Register, ISO 9001 — we deliver traceable outputs that slot into your workflow.

How We Deliver Marine Metrology

Mobile teams integrate laser trackers and 3D scanners with Spatial Analyzer, PolyWorks,
Metrolog, V-Stars, and Geomagic. Clear visuals and same-day, actionable reporting.
Explore 3D Inspection,
Precision Alignment,
Reverse Engineering.

Worldwide mobilisation
Traceable datasets
Fast turnaround

Why Teams Choose TNT
  • Speed & clarity — live feedback, intuitive visuals, concise reports.
  • Right-first-time fit-ups — less hot-work, less rework, shorter dock time.
  • Scalable support — single machinery seats to full vessel surveys.
  • Auditable outputs — class-ready documentation.
Related Services

Ready to de-risk your next docking?

Tell us about your shaft line, block fit-ups, or retrofit and we’ll recommend the most efficient marine metrology plan.

Get a Quote

External resources: International Maritime Organization (IMO) ·
International Association of Classification Societies (IACS) ·
DNV Maritime

Get Your Next Docking Done Right

Get A Quote

FAQs

We support shaft lines, gearboxes, main/aux engines, rudders, propellers, stabilisers, foundations, and mission equipment using precision alignment and trackers.

Yes. Our 3D scanning captures large hull sections, tanks, and superstructures for fairing analysis, deflection checks, and retrofit planning.

Absolutely. We produce traceable, auditable reports suitable for class review, aligned to your QA system and dimensional inspection standards.

Yes. Our reverse engineering workflows create accurate CAD for obsolete components, mounting interfaces, and piping tie-ins.

We offer worldwide mobilisation and can deploy on short notice for urgent dockings, emergent repairs, or voyage-repair inspections.
